FITS: Jeep JL/JLU Wrangler (2018+), Jeep JT Gladiator (2020+)
• Geometry Correction for Lifted Jeeps
Designed as the definitive fix when lifting a JL or JT over 2”.
Raising the front track bar mount on the axle side corrects key suspension geometry issues:
-
Recenters the axle under the vehicle
-
Raises front roll center to improve stability
-
Flattens drag link and track bar angles at ride height
-
Minimizes axle shift during suspension travel
• High-Strength Construction
Engineered by Synergy for durability and performance in off-road conditions
Works in conjunction with high steer drag link configuration
• Installation Requirements
-
Drag link must be flipped above the knuckle (high steer) to use this bracket
-
Minimum 3” bump stop spacing required
-
Maximum 4.75” wheel backspacing to clear drag link in flipped position
• Warranty
Warranties are covered directly through Synergy
Key Specifications
Compatibility: Jeep JL/JLU Wrangler (2018+), Jeep JT Gladiator (2020+)
Position: Front Axle Side
Use Case: Lifted Jeeps (2”+ lift)
Requirements: High Steer Drag Link, Bump Stops, Max Wheel Backspacing
