• Vehicle-Specific Performance Tuning
Delivers a comfortable on-road ride and predictable off-road handling using race-proven damping control.
• Internal Floating Piston Design
Separates shock oil from high-pressure nitrogen gas to eliminate oil aeration and maximize performance.
• Durable Aluminum Construction
2.0" impact-extruded and CNC-machined 6061-T6 aluminum body increases cooling capacity and resists rust over time.
• High-Performance Components
Includes black-anodized CNC-machined aluminum parts, 5/8" hard chrome plated heat-treated alloy steel shaft, and race-developed high-flow piston.
• Application-Specific Valving
Factory-tuned precision valving optimized for each application to ensure consistent ride quality under tough conditions.
• Redundant Seal Pack System
Main seal, wiper seal, and scraper seal work together for enhanced durability and leak resistance.
Key Specifications
Series: Performance
Travel: 9.62
Body: 2.0" impact-extruded & CNC-machined 6061-T6 aluminum
Body Plating: Clear-anodized
Components: Black-anodized CNC-machined 6061-T6 aluminum
Shaft: 5/8" hard chrome plated heat-treated alloy steel
Piston: Race-developed high-flow piston design
Valving: Application specific
Seals: Redundant sealing pack (main seal, wiper, scraper)
Extended Length: 25.92
Compressed Length: 16.3
Top Mount: Eyelet
Bottom Mount: Eyelet
Fitment Notes: Excludes Mojave Model
Fitment
• 2018–2025 Jeep Wrangler – All – Front
• 2020–2025 Jeep Gladiator – All – Front (Excludes Mojave Model)
